Self-Propelled Off-Road Scissor Lift

Tiny sub heading that focuses on the topic mentioned above

Self-Propelled Off-Road Scissor Lift

HuaShi self-propelled track scissor lift is specially designed for rough terrain and uneven ground.

Equipped with steel tracks and strong hydraulic system, it ensures great traction, stability and climbing ability.

It features small turning radius, precise control, wired & wireless anti-collision systems and flexible configurations.

High-strength fork frame and full proportional control for smooth, comfortable operation.
Large load & space, foldable for transport, extendable to expand working range.
Adapts to slopes, legs move simultaneously to avoid deformation.
Efficient motor drive, eco-friendly, safe and long-lasting.
Integrated 4WD, anti-slip differential, excellent off-road performance.
Tell us about your application, operators, and work demands. Our team will help you design the ideal solution to keep your cost running at peak performance.

WE WILL QUOTE YOU WITHIN ONE HOUR

    Specifications

    ModelS1023RTS1323RTS1623RT
    Specifications
    Max. Working height12.0m15.1ｍ18.2m
    Max. Platform height10.0m13.1ｍ16.2m
    Overall length4.88m4.88ｍ4.88m
    Overall width2.30m2.30ｍ2.30m
    Overal height (unfolded fence)2.75m2.95ｍ3.15m
    Overall height (folded fence)2.1m2.3ｍ2.5m
    Work plaform dimensions
    (length x width)    		3.98*1.833.98*1.833.98*1.83
    Platform extension size1.5m front / 1.2m back

    		1.5m front / 1.2m back

    		1.5m front / 1.2m back
    Wheelbase2.85m2.85m2.85m
    Ground clearance360mm360mm360mm
    Performance
    Maximum number of employees774
    RATED LOAD1150kg680kg680kg
    Extended platform rated load230kg230kg230kg
    Machine travel speed (retracted state)6.1km/h6.1km/h6.1km/h
    Machine travel speed (lifting state)1.1km/h1.1km/h1.1km/h
    Rise/tall time50/35s55/45s60/50s
    Gradeability50%50%40%
    Minimum turning radius (inner wheel)2.16m2.16m2.16m
    Minimum tumning radius (outer wheel)5.33m5.33m5.33m
    Maximum allowable angle for work
    (front and back)    		3°3°3°
    Maximum allowable angle for work
    (lateral,leg retraction)    		2°2°2°
    Maximum alowable angle for work
    (front and back, leg extension)    		0.8°0.8°0.8°
    Maximum leg leveling angle
    (front and rear)    		7°7°7°
    Maximum allowable angle for work (lateral)12°12°12°
    Drive4WD，2WS4WD，2WS4WD，2WS
    Tire33x12-20/Solid foam-filled33x12-20/Solid foam-filled33x12-20/Solid foam-filled
    Power
    Power sourceDeutz D2.9L,Stage 5,36KWDeutz D2.9L,Stage 5,36KWDeutz D2.9L,Stage 5,36KW
    Control voltage12V DC12V DC12V DC
    Fuel tank capacity110L110L110L
    Hydraulic system capacity110L110L110L
    Weight
    Whole machine weight6950ｋｇ7230kg8020kg
